Innovative and creative WaterMark 12 water softening system.

**WATERMARK 12** is an innovative and creative water softening system.

**WATERMARK** series water softeners offer maximum comfort and have a long service life. Thanks to the **HE Electronic Demand** operating system, salt and water consumption is reduced by 50% compared to standard systems. Thus, the system is ecological.

The modern **ELECTRONIC DEMAND** control panel allows easy and intuitive programming. The multilingual system can process different units of measurement (metric units, etc.). There's also a vacation setting, which runs short, regular cleaning cycles to keep the resin bed working and prevent water from building up in the softener while on vacation.

The hydraulic valve, manufactured from highly durable Noryl, ensures maximum reliability with minimum maintenance. In addition, the standard **Stratos** system has a separation connection for maintenance work, a mixing valve for residual hardness and a safety valve for saline solution.

**Operation:**

Water softening is achieved through an ion exchange process. For this purpose, the system uses resins with the chemical property of absorbing calcium (Ca) and magnesium (Mg) ions and removing them from the water.

When the calcium and magnesium ions are absorbed by the resin, two sodium (Na) ions are released, which form more soluble salts due to their chemical properties, thus avoiding all the problems associated with water hardness. Therefore, the sodium concentration in water increases when it is softened.

The ion exchange resin filling is located in the water softener column and occupies a significant part of the total volume (between 60 and 70%, depending on the model). A portion of the column must remain empty to allow proper regeneration of the resin bed.

During the treatment process, water enters the multi-way valve through the inlet port, flows into the top of the tank through the top outlet, and moves down through the resin bed where ion exchange takes place.

The treated water is collected through the inner pipe of the tank and sent for consumption through the outlet connection. At this point, the system has a treated water meter to measure the amount of processed water.

**Regeneration:**

The amount of calcium and magnesium ions that the resin can absorb is limited. Therefore, the amount of water that the softener can treat is also limited.

The system must periodically perform a regeneration process, in which the resin is enriched again with sodium ions, to continue softening the water.

At **WATERMARK**, the regeneration process starts automatically when the preset amount of water is reached. The programming device allows the user to set several regeneration initiation modes.

**Backwash:**

Water enters the column through the lower distribution pipe, washes the floating material and agitates the resin bed, thus facilitating the subsequent regeneration process.

**Saline Aspiration:**

Through the aspiration process, based on the Venturi effect, the system aspirates the saline solution, which was previously prepared in the regeneration tank. This saline solution is directed down into the softening column where it contacts the ion exchange resin and regenerates it.

Because **WATERMARK** is designed for long durability and to give you many years of high-quality service, we offer a full 10-year machine warranty.

**CHARACTERISTICS:**

The **WATERMARK 12** compact softening system is an innovative, high-quality device. The water softener features a color display with an intuitive menu in German.

**WATERMARK 12** is an innovative and creative top softening system with a removable control unit.

The controller with display can be easily detached from the housing, allowing easy setup and programming of the control valve even in very tight spaces with limited access.

The included bypass valve makes installation of the device extremely simple and thus reduces installation costs. In addition, the bypass valve ensures an uninterrupted supply of potable water even during maintenance work. With the integrated mixing valve, the desired residual hardness can be precisely adjusted.

**WATERMARK 12** was developed to regulate or reduce the content of calcium and magnesium in water to the desired level. These minerals cause water hardness and the formation of limescale deposits. The central softening system completely eliminates the problem of limescale stains in kettles, coffee machines, bathroom and kitchen taps and other household appliances.

**WATERMARK 12** is an innovative and creative top softening system with a removable control unit.

Our high-quality softening system offers the best quality and maximum safety for the #1 food and delivers soft, delicate water to every faucet in an apartment, home or business.

**What are the advantages of a WATERMARK central softening system?**

- **Health** – soft water helps the skin to be healthy, smooth and soft
- **Cleanliness** – soft water is free of minerals that threaten heating systems and household appliances
- **Beauty** – soft water significantly improves the condition of the hair, giving it shine and natural suppleness
- **Economy** – washing with soft water only requires about 50% of the amount of detergent, because soft water fights dirt and stubborn stains better
- **Energy efficiency** – the efficiency of water heating systems is considerably increased
- **Protection** – lime-free water protects the colors of clothes with every wash

Package Contents:

1x Water softening system **WATERMARK 12**
